PolyPhaser
PolyPhaser 2-6 Ghz Bulkhead Mount Coax Protector, N-Female
(No reviews yet)
Write a Review
- SKU:
- AL-LSXM
- UPC:
- 748528970695
- MPN:
- AL-LSXM
- Condition:
- New
- Availability:
- In Stock - Ships Next Day
- Minimum Purchase:
- 1 unit
- Shipping:
- Calculated at Checkout
Frequently bought together:
Description
Manufacturer Part Number: AL-LSXM
Polyphaser AL-LSXM SX is Water Type Coax Protector 2 GHz-6 GHz. DC Block Lightning Protection N-Femae connectors at both ends.It is Bulkhead Mounted.
Key Features
- Frequency Range: 2GHz - 6 GHz
- Insertion Loss less than 0.7 dB
- Repeatable RF performance after surge
- Weather-proof when installed
- Bulkhead Mount and Aluminium material
| Key Specifications | |
| Device Type | Coax Protection |
| Electrical Specification | |
| Frequency Range | DC - 6 GHz |
| Rated Impulse Discharge (8/20us Wave) | 10 kA |
| Max Power | 10 Watts |
| Insertion Loss (at Fmax) | 0.1 dB |
| VSWR | 1.2 :1 |
| Impedance | 50 Ohms (Ω) |
| Mechanical Specification | |
| Dimensions (Inches) | 0.7 Dia x 2.72 Height |
| Weight | 0.2 lb |
| Operating Temperature | -40 degF to 185 degF |
| Weatherproofing | IP67 |
| Connector 1 | N-Female |
| Connector 2 | N-Female |
| Please contact an RFWEL Remote Power Solutions Specialist if you have questions on the specs. | |
| Compare Related Lightning Protection Specs | |||
| Item | Rated Discharge (8/20us) | Max Frequency | Connectors |
|
AL6-NFNFBW-9
| 6 GHz | N-Female (Bulkhead) - N-Female | |
|
AL6-NMNFBW-9
| 6 GHz | N-Male - N-Female (Bulkhead) | |
|
AL-LSXM-MA
| 3 kA | 6 GHz | N-Female - N-Male |
|
AL-LSXM-ME
| 3 kA | 6 GHz | N-Female - N-Male |
|
AL-NFNFB-9
| 5 kA | 3 GHz | N-Female (Bulkhead) - N-Female |
|
BGXZ-60NFNF-ALT
| 20 kA | 0.5 GHz | N-Female - N-Female |
|
DGXZ+15TFTF-A (MPN: DGXZ+15TFTF-A)
| 20 kA | 2.5 GHz | TNC-Female - TNC-Female |
|
IS-50NX-C0
| 50 kA | 0.7 GHz | N-Female - N-Female |
|
IS-50NX-C0-MA
| 50 kA | 0.7 GHz | N-Male - N-Female |
|
IS-50NX-C0-ME
| 50 kA | 0.7 GHz | N-Female - N-Male |
|
IS-50NX-C2-MA
| 50 kA | 1 GHz | N-Female - N-Male |
|
IS-50NX-C2-ME
| 50 kA | 1 GHz | N-Female - N-Male |
|
IS-50UX-C0
| 50 kA | 0.7 GHz | UHF Female - UHF Female |
|
IS-50UX-C1-ME
| 50 kA | 0.7 GHz | UHF Female - UHF Male |
|
IS-75F-C1
| 50 kA | 0.7 GHz | F-Female - F-Female |
|
IS-B50HN-C2
| 20 kA | 1 GHz | N-Female - N-Female |
|
IS-B50LN-C0
| 20 kA | 1 GHz | N-Female - N-Female |
|
IS-B50LN-C2-ME
| 20 kA | 1 GHz | N-Female - N-Female |
|
IS-NEMP-C2
| 50 kA | 1 GHz | N-Female - N-Female |
|
LTNG-2400-GDFF
| 20 kA | 2.4 GHz | N-Female - N-Female |
|
LTNG-2400-GDMF
| 20 kA | 2.5 GHz | N-Female - N-Male |
|
LTNG-5800-GDFF
| 5.8 GHz | ||
|
TSX-NFF
| 40 kA | N-Female (Bulkhead) - N-Female (Bulkhead) | |
|
TSX-NFM
| 40 kA | 2.7 GHz | N-Female - N-Female |
|
TUSX-NFF
| 40 kA | 1.2 GHz | N-Female - N-Female |
|
TW-LP-N-J-BHJ
| 20 kA | 6 GHz | N-Female (Bulkhead) - N-Female |
|
TW-LP-N-P-BHJ
| 20 kA | 6 GHz | N-Female (Bulkhead) - N-Male |
|
TW-LP-RPSMA-P-BHJ
| 20 kA | 6 GHz | RPSMA-Male (Bulkhead) - RPSMA-Female |
|
TW-LP-RPTNC-P-BHJ
| 20 kA | 6 GHz | RPTNC-Female - RPTNC-Male |
|
TW-LP-SMA-J-BHJ
| 20 kA | 6 GHz | SMA-Female (Bulkhead) - SMA-Female |
|
V-LP-N-J-BHJ
| 10 kA | 7 GHz | N-Female (Bulkhead) - N-Female |
|
V-LP-N-P-BHJ
| 10 kA | 7 GHz | N-Female - N-Male |
|
V-LP-RPSMA-P-BHJ
| 10 kA | 7 GHz | RPSMA-Male - RPSMA-Female (Bulkhead) |
. . . search for additional items with specific features using the Lightning Protection filter.
Warranty Information
Manufacturer warranty runs for 1 year from delivery date. Rfwel Engr support handles warranty repairs/replacements for this item.
View AllClose
Additional Information
Device Type: |
Coax Protection |
Weight (Lb): |
0.2 |
Weatherproofing: |
IP67 |
Max Frequency (GHz): |
6 |
Surge (8/20us Wave) (kA): |
10 |
Max Power (W): |
10 |
Max Insertion Loss (dB): |
0.1 |
VSWR (x:1): |
1.2 |
Impedance (Ohms): |
50 |
Connector 1: |
N-Female |
Connector 2: |
N-Female |
