Transtector systems

Outdoor GbE RJ45 CAT5/6 POE Lightning Surge Protector

(No reviews yet) Write a Review
SKU:
1101-1030
UPC:
748528970855
MPN:
1101-1030
Condition:
New
Availability:
contact us for ESD
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
$294.59
Frequently bought together:

Description

Manufacturer Part Number: 1101-1030

Outdoor, gigabit PoE surge protector engineered by Transtector for signal throughput for RJ-45 bulkhead mount applications

Key Features

  • Mount Type - Bulkhead
  • Maximum Continuous Operating Voltage - 90 V DC
  • Line Voltage - 48 V DC

Key Specifications
Device Type CAT5/6 Protection
Communication Protocol 10/100/1000 Ethernet
Communication Interface RJ45
Number of Ethernet Ports 1
Electrical Specification
Input Voltage (DC) 48 VDC
Power Input Interface RJ45, POE
Rated Impulse Discharge (8/20us Wave) 5 kA
Power Output Interface RJ45, POE
Output Voltage (DC) 48 VDC
Mechanical Specification
Dimensions (Inches) 4 x 1.5 x 1.5
Weight 0.25 lb
Operating Temperature -40 degF to 167 degF
Relative Humidity 99%, Non-Condensing
Weatherproofing IP67
Input Cable Type CAT5E, CAT6
Output Cable Type CAT5E, CAT6
Please contact an RFWEL Remote Power Solutions Specialist if you have questions on the specs.

Related Products

. . . search for additional items with specific features using the Lightning Protection filter.

Quick Links

Datasheet

Power Backup Solutions (for Wireless)

Select Case Studies

Support Knowledge Base

Search 1101-1030 articles

Discuss in the Forums

Search 1101-1030 posts

Ask a Question

Reference Power Solutions Drawings


Select Content

Lightning Surge Protection for Coaxial Cable Networks

View More Engineering Articles ...

View AllClose

Warranty Information

Manufacturer warranty runs for 1 year from delivery date. Rfwel Engr support handles warranty repairs/replacements for this item.
View AllClose

Additional Information

Device Type:
CAT5/6 Protection
Communication Protocol:
10/100/1000 Ethernet
Communication Interface:
RJ45
Max Input Voltage (V):
60
Power Input Interface:
RJ45
Power Input Interface:
POE
Weight (Lb):
0.25
Min Operating Temp (degF):
-40
Max Operating Temp (degF):
167
Relative Humidity (%):
99
Weatherproofing:
IP67
Input Voltage:
48 VDC
Ports:
1
Surge (8/20us Wave) (kA):
5
Power Output Interface:
RJ45
Power Output Interface:
POE
Max Output Voltage (V):
60
Input Cable Type:
CAT5E
Input Cable Type:
CAT6
Output Cable Type:
CAT5E
Output Cable Type:
CAT6
Output Voltage:
48 VDC
