L-COM

L-Com NB141207-20F 240 VAC Weatherproof Enclosure, 14x12x7"

(No reviews yet) Write a Review
SKU:
NB141207-20F
MPN:
NB141207-20F
Condition:
New
Availability:
contact us for ESD
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
$444.49
Frequently bought together:

Description

Manufacturer Part Number: NB141207-20F

L-Com NB141207-20F enclosure is designed to protect sensitive equipment from the elements and supply it with proper airflow. It features a thermostat-controlled, high flow 240 VAC fan featuring ball bearings, along with provisions for connecting AC power, data, or RF cables to the enclosure.

The enclosure is a rugged weatherproof design that is ideal for both indoor and outdoor applications. Being constructed from molded fiberglass reinforced polyester, it is well suited for high temperatures or corrosive environments. The integral mounting flange allows mounting on any flat surface. When used with its optional mounting brackets, the unit can mount to a pole or column.

Key Features

  • Has fully gasketed raised vented lid with removable filters & integral mounting flange
  • Stainless steel quick release latches with padlock hasps
  • Mounting plate with AC socket cutouts, 240 VAC terminal strip & thermostat controlled cooling system
  • NEMA type 3R, 3RX / IP24 rated
  • Molded Fiberglass Reinforced Polyester (FRP) industrial enclosure

Specifications
Device Type Outdoor Enclosure, Indoor Enclosure
Mechanical Specification
Dimensions (Inches) 15.5 x 13.5 x 8.7
Weight 12.3 lb
Color Gray
Internal Dimensions (Inches) 13.5 x 11.5 x 5.8 (Note that these dimensions are approximate. Allow enough space to mount your equipment.)
Construction Material Fiberglass
Mounting Pole Mount
Weatherproofing NEMA 3R
Additional Enclosure Features Latch Lock
Legal, Regulatory & Compliance
Compliance RoHS
Please contact an RFWEL Wireless Infrastructure Specialist if you have questions on the specs.
