Digital Loggers POE15 15V 8 Port Smart Switched Midspan POE

(No reviews yet) Write a Review
SKU:
POE15
MPN:
POE15
Condition:
New
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
$295.00
Frequently bought together:

Description

Manufacturer Part Number: POE15

 Auto-Reboot with Customized Power Control

The injector will automatically sense when an IP device goes down and reboot by power cycling. Scripting, syslog, AutoPing automatic reboot, and WOL support are standard features in every injector. Removable rack/wall mount brackets are included. Utilities like our new email alerter are free.

Ideal for WISPs
Simplify installations. Reduce cabling and clean up your installations. Eliminate the bulky UPS, separate POE injectors and power switchgear. One compact unit controls and reboots your radios securely from any web browser.

Eliminate the UPS
Directly connect an external 12V battery for true uninterrupted power without a separate UPS. The injector senses both battery and AC power, switching instantly to the best power source. The built-in trickle charger will float and fully charge anything from a small gel-cell to a car battery. Solar and wind power systems are easy to connect. 15V is the ideal power voltage for many radios. With good quality cable, 15V will provide good power to the radio without wasted heat which can reduce long-term reliability.

150W Power, Fast Surge Suppresion
Power surges, static, and nearby lightning can damage radios. Dual gas-tube and SIDAC protectors provide clean, safe POE to keep your POE equipment running rock-solid. The injector combines a passive 150W power injector -plus- an active current monitor that detects and corrects overloads. Get reliable operation through power surges and brown-outs, even on 802.3af POE+ equipment that may not negotiate reliably on other injectors and switches.

Key Specifications
Device Type POE Injector
Number of Ethernet Ports 8
Electrical Specification
Input Voltage (AC) 120 VAC
Input Voltage Range 90 - 130 V
Power Output Interface POE
Output Voltage (DC) 15 VDC
Mechanical Specification
Mounting 1U Rack Mount
Dimensions (Inches) 19 x 4.5 x 7.8
Weight 4.6 lb
Operating Temperature -30 degF to 170 degF
Relative Humidity 80%, Non-Condensing
Input Cable Type 18 AWG
Please contact an RFWEL Remote Power Solutions Specialist if you have questions on the specs.

Compare Related Power Over Ethernet (POE) Specs
Item Type Ethernet Ports
POER24

POER24 image

Power Control, Power Monitor, Remote Switch
POE48

POE48 image

POE Injector 8

. . . search for additional items with specific features using the Power Over Ethernet (POE) filter.

Quick Links

Datasheet

Power Backup Solutions (for Wireless)

Select Case Studies

Support Knowledge Base

Search POE15 articles

Discuss in the Forums

Search POE15 posts

Ask a Question

Reference Power Solutions Drawings


Select Content

Power Termination Options for Photocell Adapters

View More Engineering Articles ...

View AllClose

Warranty Information

Manufacturer warranty runs for 1 year from delivery date. Rfwel Engr support handles warranty repairs/replacements for this item.
