RFS
800 to 2200 MHz Bias-T w/ Surge Protection (7-16 DIN)
- SKU:
- BIAST311546TS2P2
- MPN:
- 716-UC90-07
- Condition:
- New
- Minimum Purchase:
- 1 unit
- Shipping:
- Calculated at Checkout
Description
Manufacturer Part Number: 716-UC90-07
The RFS BIAS-T is used to inject or extract DC currents onto the center conductor of the coaxial cable feeder. It is intended for applications such as powering of Tower Mounted Amplifiers (TMAs) and Antenna Control Units (ACUs) for Remote Electrical Tilt (RET) antenna systems.
The Bias-T is suitable for high RF performance and offers built in surge protection of outdoor mobile communication systems requiring DC power.The surge protection is created by the use of a high power gas capsule lightning protector with integrated high pass DC filter for DC blocking on the protected side of the component. It is rated to protect against both direct and indirect multiple strikes in the harshest environments imaginable. Its rugged construction utilizes solid metal housings, beryllium-copper contacts and superior plating, which results in outstanding system protection and operating continuity.
Bias-T with Surge Protection 7-16 DIN, 800 to 2200 MHz.
Key Features
- RF peak power not limited by gas capsule
- Superior RF performance, PIM level lower ? 150 dBc available
- Availability for applications from 380 to 2500 MHz
- Safe extinguishing of capsule after having conducted a surge current to ground
- RG316 Jumper, single ended with TNC Male Connector, 25ft length
| Key Specifications | |
| Device Type | Coax Protection |
| Frequency Bands | 1.9 GHz, 1880 - 1900 MHz, 800 MHz, 868 MHz (ISM), 900 MHz, 900 MHz (ISM) |
| Electrical Specification | |
| Frequency Range | DC - 2.2 GHz |
| Insertion Loss (at Fmax) | 0.15 dB |
| VSWR | 1.253 :1 |
| Mechanical Specification | |
| Dimensions (Inches) | 6 x 6 x 2 |
| Weight | 2 lb |
| Connector 1 | 7/16 DIN Male |
| Connector 2 | 7/16 DIN Female |
| Please contact an RFWEL Remote Power Solutions Specialist if you have questions on the specs. | |
Related Products
. . . search for additional items with specific features using the Lightning Protection filter.
Warranty Information
Additional Information
Device Type: |
Coax Protection |
Frequency Bands: |
1.9 GHz |
Frequency Bands: |
1880 - 1900 MHz |
Frequency Bands: |
800 MHz |
Frequency Bands: |
868 MHz (ISM) |
Frequency Bands: |
900 MHz |
Frequency Bands: |
900 MHz (ISM) |
Weight (Lb): |
2 |
Max Frequency (GHz): |
2.2 |
Max Insertion Loss (dB): |
0.15 |
VSWR (x:1): |
1.253 |
Connector 1: |
7/16 DIN Male |
Connector 2: |
7/16 DIN Female |
