Ubiquiti

Ubiquiti Networks ETH-SP-G2 - Ethernet Surge Protector Gen2

(No reviews yet) Write a Review

SKU:: ETH-SP-G2
UPC:: 748528963758
MPN:: ETH-SP-G2
Condition:: New
Availability:: In Stock - Ships Next Day
Minimum Purchase:: 1 unit
Shipping:: Calculated at Checkout

$19.89

Current Stock:

Quantity:

Frequently bought together:

Description
Warranty Information
Additional Information

Description

Manufacturer Part Number: ETH-SP-G2

The ETH-SP-G2 from Ubiquiti Network is a cost-effective solution for protecting outdoor Ethernet devices from damaging electrostatic discharge and surges. It is engineered to protect Power-over-Ethernet (PoE) or non-PoE devices with connection speeds of up to 1 Gbps. Two passive, surge-protected RJ45 connections provide maximum equipment compatibility.

Key Features

Compatiable with Gigabit Networks.
2 RJ45 Female Connectors with IEEE 802.3af PoE Support
Plug and Play (EASY) Installation.
Absorbs Transient Current with Response to Surge Voltage from 100V/s to 1kV/microsecond
Discharge Current of 10kA+

Key Specifications
Device Type	CAT5/6 Protection
Color	White
Electrical Specification
Power Input Interface	RJ45
Rated Impulse Discharge (8/20us Wave)	10 kA
Power Output Interface	RJ45
Mechanical Specification
Mounting	Pole Mount, Wall Mount
Dimensions (Inches)	3.58 x 2.4 x 1.28
Weight	0.2 lb
Operating Temperature	-22 degF to 149 degF
Relative Humidity	90%, Non-Condensing
Input Cable Type	CAT5E, CAT6
Output Cable Type	CAT6, CAT5E
Please contact an RFWEL Remote Power Solutions Specialist if you have questions on the specs.

Compare Related Lightning Protection Specs
Item	Rated Discharge (8/20us)	Max Frequency	Connectors
ESP-100-POE	10 kA
TP-ESP-1000-POE	5 kA
TP-ESP-1000-POE24	5 kA
TP-ESP-100-POE24	5 kA
TP-ESP-10G-POE	10 kA
TP-ESP-1G-24RM	10 kA

. . . search for additional items with specific features using the Lightning Protection filter.

Quick Links

Datasheet

Power Backup Solutions (for Wireless)

Select Case Studies

Support Knowledge Base

Search ETH-SP-G2 articles

Discuss in the Forums

Search ETH-SP-G2 posts

Ask a Question

Reference Power Solutions Drawings

Select Content

Lightning Surge Protection for Coaxial Cable Networks

View More Engineering Articles ...

View AllClose

Warranty Information

Manufacturer warranty runs for 1 year from delivery date. Rfwel Engr support handles warranty repairs/replacements for this item.

View AllClose

Additional Information

Device Type:	CAT5/6 Protection
Color:	White
Power Input Interface:	RJ45
Mounting:	Pole Mount
Mounting:	Wall Mount
Weight (Lb):	0.2
Min Operating Temp (degF):	-22
Max Operating Temp (degF):	149
Relative Humidity (%):	90
Surge (8/20us Wave) (kA):	10
Power Output Interface:	RJ45
Input Cable Type:	CAT5E
Input Cable Type:	CAT6
Output Cable Type:	CAT6
Output Cable Type:	CAT5E
