Mobile Mark

LTMWG942-A3CB3CW3J00-WHT-120-SP529 4xLTE/2xWIFI 6E (6 cables) White Radome

(No reviews yet) Write a Review
SKU:
LTMWG942
MPN:
LTMWG942
Condition:
New
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
$370.55
Frequently bought together:

Description

Manufacturer Part Number: LTMWG942

The LTMWG942 is a compact, 6-cable antenna featuring 4x 5G/LTE, 2x WiFi 6E or Bluetooth, and 1x GNSS connections. With up to seven integrated antenna elements in a streamlined design, it ranks among the smallest antennas available. The four cellular elements support Single-Carrier 4x MIMO 5G or Dual-Carrier 2x MIMO 5G, and all 5G antennas are fully backward compatible with 4G LTE. The two WiFi 6E elements enable high-speed connectivity for advanced 802.11ax WiFi applications.

Key Features

  • Multiband: 4x 5G/LTE, 2x WiFi 6E, 1x GNSS
  • Dual-Carrier 2x MIMO 5G or Single-Carrier 4x MIMO 5G
  • 1 ft Cable Pigtails Exit Antenna; 14 ft Cable Jumpers Provided
  • Dual-Carrier 2x MIMO 5G or Single-Carrier 4x MIMO 5G

Key Parameters
Compatible Brands Universal
Electrical Specification
Frequency 694 - 960 MHz 1710 - 7200 MHz 2400 - 2500 MHz 4900 - 7200 MHz
Impedance 50 Ohms
Max Power 10 Watts
Mechanical Specification
Dimensions (Inches) 5.5 Dia x 2.38 Height
Operating Temperature -40 degF to 176 degF
Weatherproofing IP69K
Please contact an RFWEL Indoor Coverage specialist if you have questions on the specs.

Related Products

. . . search for additional items with specific features using the Antennas filter.

Quick Links

Antenna Boosters

Low Loss Coaxial Cables

Indoor coverage solutions

Best LTE Antennas

Search Cable Adapters

Support Knowledge Base

Search LTMWG942 articles

Discuss in the Forums

Search LTMWG942 posts

Ask a Question

Reference Indoor Coverage Drawings

View AllClose

Warranty Information

Manufacturer warranty runs for 1 year from delivery date. Rfwel Engr support handles warranty repairs/replacements for this item.
View AllClose

Additional Information

Compatible Brand:
Universal
Min Operating Temp (degF):
-40
Max Operating Temp (degF):
176
Weatherproofing:
IP69K
Min Frequency (MHz):
694
Max Frequency (MHz):
7200
Impedance (Ohms):
50
Max Power (Watts):
10
