PolyPhaser

IS-50UX-C0 UHF F/F Coaxial RF Surge Protector, 1.5MHz - 700MHz, DC Block

(No reviews yet) Write a Review
SKU:
IS-50UX-C0
UPC:
748528970817
MPN:
IS-50UX-C0
Condition:
New
Availability:
In Stock - Ships Next Day
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
$94.99
Frequently bought together:

Description

Manufacturer Part Number: IS-50UX-C0

IS-50UX-C0 radio frequency surge protector/ lightning surge arrestor protects equipment from electromagnetic pulse (EMP) or power surges commonly caused by lightning or other strong electrical changes. Incorporates a blocking cap and gas tube technology to provide protection for equipment upto a max operational power of 2kW.

Applications: HF, UHF, VHF, Ham radios, remote industrial monitoring

Key Features

  • Surge current of 50kA
  • VSWR<1.2:1
  • Multi-strike capability with maximum power of 2kW
  • UHF female to UHF female connectors
  • Operational frequency range of 1.5-700 MHz

Key Specifications
Device Type Coax Protection
Electrical Specification
Frequency Range DC - 0.7 GHz
Rated Impulse Discharge (8/20us Wave) 50 kA
Insertion Loss (at Fmax) 0.1 dB
VSWR 1.2 :1
Impedance 50 Ohms (Ω)
Mechanical Specification
Dimensions (Inches) 2.45 x 1.75 x 1.5
Weight 0.3 lb
Operating Temperature -50 degF to 122 degF
Connector 1 UHF Female
Connector 2 UHF Female
Legal, Regulatory & Compliance
Compliance IEC
Please contact an RFWEL Remote Power Solutions Specialist if you have questions on the specs.

Compare Related Lightning Protection Specs
Item Rated Discharge (8/20us) Max Frequency Connectors
IS-50NX-C0

IS-50NX-C0 image

 50 kA 0.7 GHz N-Female - N-Female
IS-50NX-C0-MA

IS-50NX-C0-MA image

 50 kA 0.7 GHz N-Male - N-Female
IS-50NX-C0-ME

IS-50NX-C0-ME image

 50 kA 0.7 GHz N-Female - N-Male
IS-50UX-C1-ME

IS-50UX-C1-ME image

 50 kA 0.7 GHz UHF Female - UHF Male
IS-50NX-C2-MA

IS-50NX-C2-MA image

 50 kA 1 GHz N-Female - N-Male
IS-50NX-C2-ME

IS-50NX-C2-ME image

 50 kA 1 GHz N-Female - N-Male

. . . search for additional items with specific features using the Lightning Protection filter.

Quick Links

Datasheet

Power Backup Solutions (for Wireless)

Select Case Studies

Support Knowledge Base

Search IS-50UX-C0 articles

Discuss in the Forums

Search IS-50UX-C0 posts

Ask a Question

Reference Power Solutions Drawings


Select Content

Lightning Surge Protection for Coaxial Cable Networks

View More Engineering Articles ...

View AllClose

Warranty Information

Manufacturer warranty runs for 1 year from delivery date. Rfwel Engr support handles warranty repairs/replacements for this item.
View AllClose

Additional Information

Device Type:
Coax Protection
Weight (Lb):
0.3
Min Operating Temp (degF):
-50
Max Operating Temp (degF):
122
Compliance:
IEC
Max Frequency (GHz):
0.7
Surge (8/20us Wave) (kA):
50
Max Insertion Loss (dB):
0.1
VSWR (x:1):
1.2
Impedance (Ohms):
50
Connector 1:
UHF Female
Connector 2:
UHF Female
