Havis

ChargeGuard 12V Negative Ground Automatic ON/OFF Timer Switch

(No reviews yet) Write a Review
SKU:
CG-X
UPC:
748528970343
MPN:
CG-X
Condition:
New
Availability:
In Stock - Ships Next Day
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
$149.69
Frequently bought together:

Description

Manufacturer Part Number: CG-X

The Havis ChargeGuard Select CG-X automatic on/off timer switch acts as a vehicle power management system that automatically turns on mobile equipment when starting motor vehicle. This power control module also turns off peripherals after pre-set time and includes a diagnostic LED display which indicates level of battery voltage (too low or too high).

The ChargeGuard delay timer switch has a selectable timeout delay. When turning the motor off, the equipment can stay on from 5 seconds to infinity depending on what is programmed. This programmable timer delay switch comes pre-programmed with a two-hour delay as the default setting.

This on/off timer switch wires directly to the battery or ignition switch in your vehicle. The ChargeGuard features your choice of sensing mode, automatic detection mode (AC), isolated alternator detection, voltage rise detection (DC only), or direct ignition mode (HL), depending on your preference.

Key Features

  • Designed for 2-way radios, mobile data terminals, laptop computers, & other mobile / data devices
  • Protects mobile Electronics from voltage anomalies
  • Regulated by a programmable timer, Selectable Timeout Delay and 30 Amps Load Current Rating
  • Has Selectable Switch Modes, High & Low Voltage Disconnect and Reverse Polarity Protection
  • Works with many applications in multiple modes

Key Specifications
Device Type Low-Voltage Disconnect, High-Voltage Disconnect, Timer Switch
Additional Features Programmable delay switch, Load Detection (AC Sense), Battery Sense (DC Rise), Ignition Switch
Electrical Specification
Number of Voltage Measurements 1
Low Disconnect Voltage 11 V
High Disconnect Voltage 18 V
Mechanical Specification
Dimensions (Inches) 3.8 x 3.7 x 1.3
Weight 0.4 lb
Please contact an RFWEL Remote Power Solutions Specialist if you have questions on the specs.

Related Products

. . . search for additional items with specific features using the Power Monitor & Control filter.

Quick Links

Datasheet

Power Backup Solutions (for Wireless)

Select Case Studies

Support Knowledge Base

Discuss in the Forums

Ask a Question

Reference Power Solutions Drawings


Select Content

Digital Loggers LPC9 Pro Web Power Switch and Control Unit Operations

6 Best PDUs

View More Engineering Articles ...

View AllClose

Warranty Information

Manufacturer warranty runs for 1 year from delivery date. Rfwel Engr support handles warranty repairs/replacements for this item.
View AllClose

Additional Information

Device Type:
Low-Voltage Disconnect
Device Type:
High-Voltage Disconnect
Device Type:
Timer Switch
Weight (Lb):
0.4
Additional Features:
Programmable delay switch
Additional Features:
Load Detection (AC Sense)
Additional Features:
Battery Sense (DC Rise)
Additional Features:
Ignition Switch
Voltage Measurements:
1
Low Disconnect Voltage (V):
11
High Disconnect Voltage (V):
18
