Samlex America - 30-60-24V Converter, 8 Amps

(No reviews yet) Write a Review
SKU:
IDC-200C-24
MPN:
IDC-200C-24
Condition:
New
Availability:
contact us for ESD
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
$204.95
Frequently bought together:

Description

Manufacturer Part Number: IDC-200C-24

IDC-200 series is a complete line of high efficiency 200 Watt isolated DC-DC converters suitable for applications requiring galvanic isolation between the input and the output. IDC-200C-24 isolated DC-DC converter provides a highly regulated output DC voltage of 24.5 Volts for an input DC voltage range of 30-60 Volts and rated output current of 8 Amps (at 60 Volts input).

Features of this isolated DC-DC converter include compact housing, fold-back current limiting and protection against short circuit, overheating, overvoltage and reverse polarity connection. The unit comes with 1/4-inch push-on flat blade ?quick disconnect? connectors.

Key Features

  • Ouput voltage of 24.5 VDC
  • Quick connect male 6.3mm flat blade input/output connections

Key Specifications
Device Type DC/DC Step-Down (Buck)
Additional Features Over Current Protection, Over Temperature Protection, Over Voltage Protection, Short Circuit Protection
Electrical Specification
Input Voltage (DC) 48 VDC
Input Voltage Range 30 - 60 V
Power Input Interface Quick connect male 6.3mm/ 1/4" flat blade
Power Output Interface Quick connect male 6.3mm/ 1/4" flat blade
Output Voltage (DC) 24.5 VDC
Output Current 8 A (continuous current)
Efficiency 85 %
Mechanical Specification
Dimensions (Inches) 6.9 x 3.5 x 1.9
Weight 1.4 lb
Operating Temperature -4 degF to 86 degF
Relative Humidity 95%, Non-Condensing
Please contact an RFWEL Remote Power Solutions Specialist if you have questions on the specs.

Compare Related DC-DC Converters Specs
Item Type Input Voltage Output Voltage
IDC-200A-24

IDC-200A-24 image

DC/DC Step-Up (Boost) 12 VDC 24.5 VDC
IDC-360A-24

IDC-360A-24 image

DC/DC Step-Up (Boost) 12 VDC 24 VDC
STEP10 (MPN: STEP 10)

STEP10 image

DC/DC Step-Up (Boost) 12 VDC 24 VDC
SDC-30

SDC-30 image

DC/DC Step-Down (Buck) 24 VDC 12 VDC
SD-350B-48

SD-350B-48 image

DC/DC Step-Up (Boost) 24 VDC 48 VDC
SD-200B-12

SD-200B-12 image

DC/DC Step-Down (Buck) 24 VDC 12 VDC
SD-200B-24

SD-200B-24 image

DC/DC Step-Down (Buck), DC/DC Step-Up (Boost) 24 VDC 24 VDC
SD200B-48 (MPN: SD-200B-48)

SD200B-48 image

DC/DC Step-Up (Boost) 24 VDC 48 VDC

. . . search for additional items with specific features using the DC-DC Converters filter.

Quick Links

Datasheet

Power Backup Solutions (for Wireless)

Select Case Studies

Support Knowledge Base

Discuss in the Forums

Ask a Question

Reference Power Solutions Drawings

View AllClose

Warranty Information

Manufacturer warranty runs for 1 year from delivery date. Rfwel Engr support handles warranty repairs/replacements for this item.
View AllClose

Additional Information

Device Type:
DC/DC Step-Down (Buck)
Min Input Voltage (V):
30
Max Input Voltage (V):
60
Power Input Interface:
Quick connect male 6.3mm/ 1/4" flat blade
Weight (Lb):
1.4
Min Operating Temp (degF):
-4
Max Operating Temp (degF):
86
Relative Humidity (%):
95
Input Voltage:
48 VDC
Additional Features:
Over Current Protection
Additional Features:
Over Temperature Protection
Additional Features:
Over Voltage Protection
Additional Features:
Short Circuit Protection
Power Output Interface:
Quick connect male 6.3mm/ 1/4" flat blade
Output Current (A):
8
Efficiency (%):
85
Output Voltage:
24.5 VDC
